Commit-edge Architecture

Introduction

Commit-edge architecture is a specific replication configuration. It is a good solution for geographically distributed work groups, and it offers significant performance advantages. At a minimum it is made up of the following kinds of servers:

  • A commit server that stores the canonical archives and permanent metadata. In working terms, it is similar to a Perforce master server, but might not contain all workspace information.

  • An edge server that contains a replicated copy of the commit server data and a unique, local copy of some workspace and work-in-progress information. It can process read-only operations and operations like p4 edit that only write to the local data. In working terms, it is similar to a forwarding replica, but contains local workspace data and can handle more operations with no reliance on the commit server. You can connect multiple edge servers to a commit server.

Since an edge server can handle most routine operations locally, the edge-commit architecture offloads a significant amount of processing work from the commit server and reduces data transmission between commit and edge servers. This greatly improves performance.

From a user's perspective, most typical operations until the point of submit are handled by an edge server. As with a forwarding replica, read operations, such as obtaining a list of files or viewing file history, are local. In addition, with an edge server, syncing, checking out, merging, resolving, and reverting files are also local operations.

Commit-edge architecture builds upon Perforce replication technology. You should read “Perforce Replication” before attempting to deploy a commit-edge configuration.

An edge server can be used instead of a build farm server, and this usage is referred to as a build edge server. If the only users of an edge server are build processes, then your backup (disaster recovery) strategy may be simplified as you do not need to backup the local edge server-specific workspace and related information. See Migrating from existing installations.

The next figure illustrates one possible commit-edge configuration: a commit server, communicating with two edge-servers, each of which handles multiple workspaces.

Setting up a commit/edge configuration

This section explains how you set up a commit/edge configuration on Linux. It assumes that you have an existing server that you want to convert to a commit server. For the sake of this example, we'll assume that the existing server is in Chicago, and that we need to set up an edge server at a remote site in Tokyo.


  • Commit server
    P4PORT=chicago.perforce.com:1666
    >P4ROOT=/chicago/p4root


  • Edge server
    P4PORT=tokyo.perforce.com:1666
    P4ROOT=/tokyo/p4root

The setup process, which is described in detail in the following sections includes the following major steps:

  1. On the commit server: Create a service user account for each edge server you plan to create.

  2. On the commit server: Create commit and edge server configurations.

  3. Create the edge server by replicating the commit server, and start the edge server.

You must have super privileges to perform these steps.

Create a service user account for the edge server

To support secure communication between the commit server and the edge server, you must create a user account of type service for each edge server you plan to deploy. It is also best practice to provide a unique name for each edge server service user.

  1. Create the service user account.

    p4 user -f svc_tokyo_edge

    In the user spec, set the user Type: field to service.

  2. Add the service user to a group with an unlimited timeout. This prevents the service user login from the edge server from timing out.

    p4 group no_timeout

    In the group spec, set the Users: field to svc_tokyo_edge and the Timeout: field to unlimited.

  3. Assign a password to the service user by providing a value at the prompt.

    p4 passwd svc_tokyo_edge

  4. Assign the svc_tokyo_edge service user super protections in the protect spec.

    p4 protect

Create commit and edge server configurations

The following steps are needed to configure the commit and edge servers.

Note

It is best to set the P4NAME and ServerID to the same value: this makes it easy to isolate configuration variables on each server in a distributed environment.

  1. Create the commit server specification:

    p4 server chicago_commit

    In the server spec, set the Services: field to commit-server and the Name: field to chicago_commit.

  2. Create the edge server specification:

    p4 server tokyo_edge

    In the server spec, set the Services: field to edge-server and the Name: field to tokyo_edge.

  3. Set the server ID of the commit server:

    p4 serverid chicago_commit

  4. This step, which sets the journalPrefix value on the commit and edge server to control the name and location of server checkpoints and rotated journals, is not required, but it is a best practice. During the replication process, the edge server might need to locate the rotated journal on the commit server; having journalPrefix defined on the commit server allows the edge server to easily identify the name and location of rotated journals:

    p4 configure set chicago_commit#journalPrefix=/chicago/backup/p4d_backup
p4 configure set tokyo_edge#journalPrefix=/tokyo/backup/p4d_backup

  5. Set P4TARGET for the edge server to identify the commit server:

    p4 configure set tokyo_edge#P4TARGET=chicago.perforce.com:1666

  6. Set the service user in the edge server configuration:

    p4 configure set tokyo_edge#serviceUser=svc_tokyo_edge

  7. Set the location for the edge server's log files:

    p4 configure set tokyo_edge#P4LOG=/tokyo/logs/tokyo_edge.log

  8. Set P4TICKETS location for the service user in the edge and commit server configuration:

    p4 configure set chicago_commit#P4TICKETS=/chicago/p4root/.p4tickets
p4 configure set tokyo_edge#p4TICKETS=/tokyo/p4root/.p4tickets

  9. Configure the edge server database and achive nodes:

    p4 configure set tokyo_edge#db.replication=readonly
p4 configure set tokyo_edge#lbr.replication=readonly

  10. Define startup commands for the edge server to periodically pull metadata and archive data.

    p4 configure set tokyo_edge#startup.1="pull -i 1"     \\get metadata every second
p4 configure set tokyo_edge#startup.2="pull -u -i 1"  \\get versioned data every second
p4 configure set tokyo_edge#startup.3="pull -u -i 1"  \\get versioned data every second

Create and start the edge server

Now that the commit server configuration is complete, we can seed the edge server from a commit server checkpoint and complete a few more steps to create it.

  1. Take a checkpoint of the commit server, but filter out the database content not needed by an edge server.

    p4d -r /chicago/p4root -K db.have, db.working, db.resolve, db.locks, db.revsh,
      db.workingx, db.resolvex -jd edge.ckp

  2. Recover the checkpoint into the edge server P4ROOT directory.

    p4d -r /tokyo/p4root -jr edge.ckp

  3. Set the server ID for the newly seeded edge server:

    p4d -r /tokyo/p4root -xD tokyo_edge

  4. Create the service user login ticket in the location specified in the edge configuration:

    export p4TICKETS=/tokyo/p4root/.p4tickets
p4 -u svc_tokyo_edge -p chicago.perforce.com:1666 login

  5. Start the edge server and check the status of replication by running the following command against the edge server.

    p4 pull -lj

  6. Create the service user login ticket from the commit to the edge server. On the commit server:

    export p4TICKETS=/chicago/p4root/.p4tickets
p4 -u svc_tokyo_edge -p tokyo.perforce.com:1666 login

Migrating from existing installations

The following sections explain how you migrate to an edge-commit architecture from an existing replicated architecture.

Replacing existing proxies and replicas

If you currently use Perforce proxies, evaluate whether these should be replaced with edge servers. If a proxy is delivering acceptable performance then it can be left in place indefinitely. You can use proxies in front of edge servers if necessary. Deploying commit and edge servers is notably more complex than deploying a master server and proxy servers. Consider your environment carefully.

Of the three types of replicas available, forwarding replicas are the best candidates to be replaced with edge servers. An edge server provides a better solution than a forwarding replica for many use cases.

Build replicas can be replaced if necessary. If your build processes need to issue write commands other than p4 sync, an edge server is a good option. But if your build replicas are serving adequately, then you can continue to use them indefinitely.

Read-only replicas, typically used for disaster recovery, can remain in place. You can use read-only replicas as part of a backup plan for edge servers.

Deploying commit and edge servers incrementally

You can deploy commit and edge servers incrementally. For example, an existing master server can be reconfigured to act as a commit server, and serve in hybrid mode. The commit server continues to service all existing users, workspaces, proxies, and replicas with no change in behavior. The only immediate difference is that the commit server can now support edge servers.

Once a commit server is available, you can proceed to configure one or more edge servers. Deploying a single edge server for a pilot team is a good way to become familiar with edge server behavior and configuration.

Additional edge servers can be deployed periodically, giving you time to adjust any affected processes and educate users about any changes to their workflow.

Initially, running a commit server and edge server on the same machine can help achieve a full split of operations, which can make subsequent edge server deployments easier.

Hardware, sizing, and capacity

For an initial deployment of a distributed Perforce service, where the commit server acts in a hybrid mode, the commit server uses your current master server hardware. Over time, you might see the performance load on the commit server drop as you add more edge servers. You can reevaluate commit server hardware sizing after the first year of operation.

An edge server handles a significant amount of work for users connected to that edge server. A sensible strategy is to repurpose an existing forwarding replica and monitor the performance load on that hardware. Repurposing a forwarding replica involves the following:

As you deploy more edge servers, you have the option to deploy fewer edge servers on more powerful hardware, or a to deploy more edge servers, each using less powerful hardware, to service a smaller number of users.

You can also take advantage of replication filtering to reduce the volume of metadata and archive content on an edge server.

Note

An edge server maintains a unique copy of local workspace metadata, which is not shared with other edge servers or with the commit server.

Filtering edge server content can reduce the demands for storage and performance capacity.

As you transition to commit-edge architectgure and the commit server is only handling requests from edge servers, you may find that an edge server requires more hardware resources than the commit server.

Migration scenarios

This section provides instructions for several migration scenarios. If you do not find the material you need in this section, we recommend you contact Perforce support for assistance .

Configuring a master server as a commit server

Scenario: You have a master server. You want to convert your master to a commit server, allowing it to work with edge servers as well as to continue to support clients.

  1. Choose a ServerID for your master server, if it doesn't have one already, and use p4 serverid to save it.

  2. Define a server spec for your master server or edit the existing one if it already has one, and set Services: commit-server.

Converting a forwarding replica to an edge server

Scenario: You currently have a master server and a forwarding replica. You want to convert your master server to a commit server and convert your forwarding replica to an edge server.

Depending on how your current master server and forwarding replica are set up, you may not have to do all of these steps.

  1. Have all the users of the forwarding replica either submit, shelve, or revert all of their current work, and have them delete their current workspaces.

  2. Stop your forwarding replica.

  3. Choose a ServerID for your master server, if it doesn't have one already, and use p4 serverid to save it.

  4. Define a server spec for your master server, or edit the existing one if it already has one, and set Services: commit-server.

  5. Use p4 server to update the server spec for your forwarding replica, and set Services: edge-server.

  6. Update the replica server with your central server data by doing one of the following:

    • Use a checkpoint:

      1. Take a checkpoint of your central server, filtering out the db.have, db.working, db.resolve, db.locks, db.revsh, db.workingx, db.resolvex tables.

        p4d -K db.have db.working,db.resolve,db.locks,db.revsh,db.workingx,db.resolvex
        -jd my_filtered_checkpoint_file

        See the "Perforce Server Reference" appendix in the Perforce Server Administrator's Guide: Fundamentals, for options that can be used to produce a filtered journal dump file, specifically the -k and -K options.

      2. Restore that checkpoint onto your replica.

      3. Remove the replica's state file.

    • Use replication:

      1. Start your replica on a separate port (so local users don't try to use it yet).

      2. Wait for it to pull the updates from the master.

      3. Stop the replica and remove the db.have, db.working, db.resolve, db.locks, db.revsh, db.workingx, db.resolvex tables.

  7. Start the replica; it is now an edge server.

  8. Have the users of the old forwarding replica start to use the new edge server:

    1. Create their new client workspaces and sync them.

You are now up and running with your new edge server.

Converting a build server to an edge server

Scenario: You currently have a master server and a build server. You want to convert your master server to a commit server and convert your build server to an edge server.

Build servers have locally-bound clients already, and it seems very attractive to be able to continue to use those clients after the conversion from a build-server to an edge server. There is one small detail:

  • On a build server, locally-bound clients store their have and view data in db.have.rp and db.view.rp.

  • On an edge server, locally-bound clients store their have and view data in db.have and db.view.

Therefore the process for converting a build server to an edge server is pretty simple:

  1. Define a ServerID and server spec for the master, setting Services: commit-server.

  2. Edit the server spec for the build-server and change Services: build-server to Services: edge-server.

  3. Shut down the build-server and do the following:

    1. rm db.have db.view db.locks db.working db.resolve db.revsh db.workingx db.resolvex

    2. mv db.have.rp db.have

    3. mv db.view.rp db.view

  4. Start the server; it is now an edge server and all of its locally-bound clients can continue to be used!

Migrating a workspace from a commit server or remote edge server to the local edge server

Scenario: You have a workspace on a commit or remote edge server that you want to move to the local edge server.

  1. Have all the workspace owners either submit or revert all of their current work and ensure that all shelved files are deleted.

  2. p4 unload -c workspace

    Execute this command against the Perforce service where the workspace is being migrated from. In this case, this would be the commit or remote edge server.

  3. p4 reload -c workspace -p protocol:host:port

    Execute this command against the local edge server, where the workspace is being migrated to. protocol:host:port refers to the commit or remote edge server the workspace is being migrated from.

Managing distributed installations

Commit-edge architecture raises certain issues that you must be aware of and learn to manage. This section describes these issues.

  • Each edge server maintains a unique set of workspace and work-in-progress data that must be backed up separately from the commit server. See Backup and high availability / disaster recovery (HA/DR) planning for more information.

  • Exclusive locks are global: establishing an exclusive lock requires communication with the commit server, which might incur network latency.

  • Shelving changes in a distributed environment typically occurs on an edge server. Shelving can occur on a commit server only while using a client workspace bound to the commit server. Normally, changelists shelved on an edge server are not shared between edge servers.

    You can promote hangelists shelved on an edge server to the commit server, making them available to other edge servers. See Promoting shelved changelists for details.

  • Auto-creation of users is not possible on edge servers.

Moving users to an edge server

As you create new edge servers, you assign some users and groups to use that edge server.

  • Users need the P4PORT setting for the edge server.

  • Users need to create a new workspace on the edge server or to transfer an existing workspace to the new edge server. Transferring existing workspaces can be automated.

If you use authentication trigers or single sign-on, install the relevant triggers on all edge servers and verify the authentication process.

Promoting shelved changelists

Changelists shelved on an edge server, which would normally be inaccessible from other edge servers, can be promoted to the commit server. Promoted shelved changelists are available to any edge server.

Promotion occurs when shelving a changelist by using the -p option with the p4 shelve command.

For example, given two edge servers, edge1 and edge2, the process works as follows:

  1. Shelve and promote a changelist from edge1.

    edge1> p4 shelve -p -c 89

  2. The shelved changelist is now available to edge2.

    edge2> p4 describe -S 89

  3. Promotion is only required once.

    Subsequent p4 shelve commands automatically update the shelved changelist on the commit server, using server lock protection. For example, make changes on edge1 and refresh the shelved changelist:

    edge1> p4 shelve -r -c 89

    The updates can now be seen on edge2:

    edge2> p4 describe -S 89

Note

There is no mechanism to unpromote a shelved changelist; instead, delete the shelved files from the changelist.

Triggers

This section explains how you manage existing triggers in a commit-edge configuration and how you use edge type triggers.

Determining the location of triggers

In a distributed Perforce service, triggers might run either on the commit server, or on the edge server, or perhaps on both. For more information on triggers, see the Perforce Server Administrator's Guide: Fundamentals.

Make sure that all relevant trigger scripts and programs are deployed appropriately. Edge servers can affect non-edge type triggers in the following ways:

  • If you enforce policy with triggers, you should evaluate whether a change list or shelve trigger should execute on the commit server or on the edge server.

  • Edge servers are responsible for running form triggers on workspaces and some types of labels.

Trigger scripts can determine whether they are running on a commit or edge server using the trigger variables described in the following table. When a trigger is executed on the commit server, %peerip% matches %clientip%.

Trigger Variable

Description

%peerip%

The IP address of the proxy, broker, replica, or edge server.

%clientip%

The IP address of the machine whose user invoked the command, regardless of whether connected through a proxy, broker, replica, or edge server.

%submitserverid%

For a change-submit, change-content, or change-commit trigger in a distributed installation, the server.id of the edge server where the submit was run. See p4 serverid in the P4 Command Reference for details.

Using edge triggers

In addition, edge servers support two trigger types that are specific to edge-commit architecture: edge-submit and edge-content. They are described in the following table.

Trigger Type

Description

edge-submit

Executes a pre-submit trigger on the edge server after changelist has been created, but prior to file transfer from the client to the edge server. The files are not necessarily locked at this point.

edge-content

Executes a mid-submit trigger on the edge server after file transfer from the client to the edge server, but prior to file transfer from the edge server to the commit server. At this point, the changelist is shelved.

Triggers on the edge server are executed one after another when invoked via p4 submit -e. For p4 submit, edge-submit triggers run immediately before the changelist is shelved, and edge-content triggers run immediately after the changelist is shelved. As edge-submit triggers run prior to file transfer to the edge server, these triggers cannot access file content.

The following edge-submit trigger is an MS-DOS batch file that rejects a changelist if the submitter has not had his change reviewed and approved. This trigger fires only on changelist submission attempts that affect at least one file in the //depot/qa branch.

@echo off
rem REMINDERS
rem - If necessary, set Perforce environment vars or use config file
rem - Set PATH or use full paths (C:\PROGRA~1\Perforce\p4.exe)
rem - Use short pathnames for paths with spaces, or quotes
rem - For troubleshooting, log output to file, for instance:
rem - C:\PROGRA~1\Perforce\p4 info >> trigger.log
if not x%1==x goto doit
echo Usage is %0[change#]
:doit
p4 describe -s %1|findstr "Review Approved...\n\n\t" > nul
if errorlevel 1 echo Your code has not been revewed for changelist %1
p4 describe -s %1|findstr "Review Approved...\n\n\t" > nul

To use the trigger, add the following line to your triggers table:

sampleEdge   edge-submit //depot/qa/...   "reviewcheck.bat %changelist%"

Backup and high availability / disaster recovery (HA/DR) planning

A commit server can use the same backup and HA/DR strategy as a master server. Edge servers contain unique information and should have a backup and an HA/DR plan. Whether an edge server outage is as urgent as a master server outage depends on your requirements. Therefore, an edge server may have an HA/DR plan with a less ambitious Recovery Point Objective (RPO) and Recovery Time Objective (RTO) than the commit server.

If a commit server must be rebuilt from backups, each edge server must be rolled back to a backup prior to the commit server's backup. Alternatively, if your commit server has no local users, the commit server can be rebuilt from a fully-replicated edge server (in this scenario, the edge server is a superset of the commit server).

Backing up and recovering an edge server is similar to backing up and restoring an offline replica server. Specifically, you need to do the following:

  1. On the edge server, schedule a checkpoint to be taken the next time journal rotation is detected on the commit server. For example:

    p4 -p myedgehost:myedgeport admin checkpoint

    The p4 pull command performs the checkpoint at the next rotation of the journal on the commit server. A stateCKP file is written to the P4ROOT directory of the edge server, recording the scheduling of the checkpoint.

  2. Rotate the journal on the commit server:

    p4 -p mycommithost:mycommitport admin journal

As long as the edge server's replication state file is included in the backup, the edge server can be restored and resume service. If the edge server was offline for a long period of time, it may need some time to catch up on the activity on the commit server.

As part of a failover plan for a commit server, make sure that the edge servers are redirected to use the new commit server.

Note

For commit servers with no local users, edge servers could take significantly longer to checkpoint than the commit server. You might want to use a different checkpoint schedule for edge servers than commit servers. Journal rotations for edge servers could be scheduled at the same time as journal rotations for commit servers.

Other considerations

As you deploy edge servers, give consideration to the following areas.

  • Labels

    In a distributed Perforce service, labels can be local to an edge server, or global.

  • Exclusive Opens

    Exclusive opens (+l filetype modifer) are global: establishing an exclusive open requires communication with the commit server, which may incur network latency.

  • Integrations with third party tools

    If you integrate third party tools, such as defect trackers, with Perforce, evaluate whether those tools should continue to connect to the master/commit server or could use an edge server instead. If the tools only access global data, then they can connect at any point. If they reference information local to an edge server, like workspace data, then they must connect to specific edge servers.

    Build processes can usefully be connected to a dedicated edge server, providing full Perforce functionality while isolating build workspace metadata. Using an edge server in this way is similar to using a build farm replica, but with the additional flexibility of being able to run write commands as part of the build process.

  • Files with propagating attributes

    In distributed environments, the following commands are not supported for files with propagating attributes: p4 copy, p4 delete, p4 edit, p4 integrate, p4 reconcile, p4 resolve, p4 shelve, p4 submit, and p4 unshelve. Integration of files with propagating attributes from an edge server is not supported; depending on the integration action, target, and source, either the p4 integrate or the p4 resolve command will fail.

    If your site makes use of this feature, direct these commands to the commit server, not the edge server. Perforce-supplied software does not presently set propagating attributes on files and is not known to be affected by this limitation.

  • Logging and auditing

    Edge servers maintain their own set of server and audit logs. Consider using structured logs for edge servers, as they auto-rotate and clean up with journal rotations. Incorporate each edge server's logs into your overall monitoring and auditing system.

    In particular, consider the use of the rpl.checksum.* configurables to automatically verify database tables for consistency during journal rotation, changelist submission, and table scans and unloads. Regularly monitor the integrity.csv structured log for integrity events.

  • Unload depot

    The unload depot may have different contents on each edge server. Clients and labels bound to an edge server are unloaded into the unload depot on that edge server, and are not displayed by the p4 clients -U and p4 labels -U commands on other edge servers.

    Be sure to include the unload depot as part of your edge server backups. Since the commit server does not verify that the unload depot is empty on every edge server, you must specify p4 depot -d -f in order to delete the unload depot from the commit server.

  • Future upgrades

    Commit and edge servers should be upgraded at the same time.

  • Time zones

    Commit and edge servers must use the same time zone.

  • Perforce Swarm

    The initial release of Swarm can usefully be connected to a commit server acting in hybrid mode or to an edge server for the users of that edge server. Full Swarm compatibility with multiple edge servers will be handled in a follow-on Swarm release. For more detailed information about using Swarm with edge servers, please contact Perforce Support .

Validation

As you deploy commit and edge servers, you can focus your testing and validation efforts in the following areas.

Supported deployment configurations

  • Hybrid mode: commit server also acting as a regular master server

  • Read-only replicas attached to commit and edge servers

  • Proxy server attached to an edge server

Backups

Exercise a complete backup plan on the commit and edge servers. Note that journal rotation on an edge server is not allowed.
